7. PRINTING WAVEFORMS & DATA
7-2 PRINT SAMPLES
Mode 1 (Arterial)
Time scale 0.2 sec/div. (approx. 25 mm/s)
Combined forward and reverse
Mode 2 (Venous)
Time scale 1 sec/div. (approx. 5 mm/s)
Separation of arterial and venous ow velocity
5 sec. max.
0.2 sec.
25 sec. max.
1 sec.
