Smartdop
®
30EX Basic Operation
5. MODE & MENU SETTINGS
5-3 MENU (Cont.)
5-3-5 MENU FOR PPG (PHOTOPLETHYSMOGRAPHY) (MEASUREMENT & FREEZE)
For measuring and observing PPG waveforms.
Connect the PPG probe to select measurement.
Press the probe button or INF/DUMP button to select freeze; press again to exit.
Bold face selections in the table above indicate default settings.
*1 WAVEFORM is available in Mode 1 (AC) during freeze mode only.
*2 COUNT is available in Mode 2 (DC) during measurement mode only.
*3 MEMORY - STORE is available only in Freeze mode.
*4 DISCHARGE is available when the AC adaptor is connected to the main unit.
19
Menu Sub Menu Selections Reference Section
STORE (*3) 1 to 30, FREEZE 5-3-8
MEMORY READ 1 to 30, FREEZE 5-3-9
CLEAR 1 to 30, ALL 5-3-10
WAVEFORM (*1) PAGE 1, PAGE 2 5-3-13
COUNT (*2) 1 TO 20, 5 5-3-26
LANGUAGE ENGLISH, DEUTSCH, 5-3-14
ITALIANO, ESPAÑOL,
FRANÇAISE
OTHERS PRB-KEY FREEZE, PRINT, FRZ&PRINT 5-3-15
(Probe button)
BACKLIGHT ON, OFF, 10 to 60 5-3-18
(10 sec. steps)
AUTO OFF ON, OFF 5-3-19
RESET 5-3-20
DISCHARGE (*3) 5-3-21
