Smartdop
®
30EX Basic Operation
35
7. PRINTING WAVEFORMS & DATA
7-1 HOW TO PRINT
Waveforms can be printed while in Freeze mode only.
1. Press the PRINT button.
2. Smartdop
®
30EX prints the following waveforms and numerical data. Printing stops
automatically or press the PRINT button a second time to stop the printer.
Measurement Mode
(pressing the print button during measurement mode freezes the waveform prior to printing)
Mode 1: Waveform of the 5 seconds prior to printing
Mode 2: Waveform of the 25 seconds prior to printing
Freeze Mode
Mode 1: Waveform of the 5 seconds prior to freezing
Mode 2: Waveform of the 25 seconds prior to freezing
Arm/Leg and Toe Pressure Mode
Systolic pressure, ABI / TBI, and heart rate (determined by stored pressure values)
Press the PRINT button longer than 2 seconds to print the waveform and numerical data.
3. To stop the printer, press the PRINT button a second time.
NOTE
Pressing the probe button also activates the printer when the probe button function is
set to either PRINT or FRZ&PRINT.
