Hadeco Smartdop 30EX - Page 55

Smartdop
®
30EX Basic Operation
48
Guidance and Manufacturer’s Declarations (cont.)
Electromagnetic Immunity
The Smartdop
®
30EX is intended for use in the electromagnetic environment specied below. The user of
the Smartdop
®
30EX should assure that it is used in such an environment.
Immunity test IEC60601 test level Compliance level Electromagnetic environment
- guidance
Electrostatic ± 6kV contact ± 6kV contact Floors should be wood,
discharge (ESD) concrete or ceramic tile. If
± 8kV air ± 8kV air oors are covered with
IEC61000-4-2 synthetic material, the relative
humidity should be at least 30%.
Electrical fast ± 2kV for power ± 2kV for power Mains power should be that of a
transient/burst supply lines supply lines typical commercial or hospital
environment
IEC61000-4-4 ± 1kV for input/output ± 1kV for input/output
lines lines
Surge ± 1kV di󰀨erential ± 1kV di󰀨erential Mains power should be that of a
mode mode typical commercial or hospital
IEC61000-4-5 ± 2kV common mode ± 2kV common mode environment
Voltage dips, short < 5% U
T
< 5% U
T
Mains power should be that of a
interruptions and (> 95% dip in U
T
) (> 95% dip in U
T
) typical commercial or hospital
voltage variations for 0,5 cycles for 0,5 cycles environment
on power supply 40% U
T
40% U
T
input lines (60% dip in U
T
) (60% dip in U
T
)
for 5 cycles for 5 cycles
IEC61000-4-11
70% U
T
70% U
T
(30% dip in U
T
) (30% dip in U
T
)
for 25 cycles for 25 cycles
< 5% U
T
< 5% U
T
(> 95% dip in U
T
) (> 95% dip in U
T
)
for 5 s for 5 s
Power frequency 3 A/m 3 A/m Power frequency magnetic
(50/60 Hz) elds should be at levels
magnetic eld characteristic of a typical
IEC61000-4-8 location in a typical
commercial or hospital
environment
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
