HALE SmartFOAM - Elbows and Manifolds

Page 35
SmartFOAM
ELBOWS AND MANIFOLDS
Close Fit Flanged Elbow
098-0140-00-0
115 flange inlet with 3” Victaulic
output
Close Fit Flanged Elbow
098-0190-00-0
2433D flange inlet with 3” NPT
female and 4” Victaulic output
Close Fit Flanged Elbow
098-0050-00-0
115 flange inlet with 2.5” NPT fe-
male output
Close Fit Flanged Elbow
098-0020-00-0
115 flange inlet with 115 flange
output
Mini-Manifold
178-0320-02-0
