Page 96
ILLUSTRATED PARTS BREAKDOWN
GENERAL
This section contains drawings and the parts breakdown for the serviceable assemblies, components and most
commonly
used options for the SmartFOAM Electronic Foam Proportioning System.
ABBREVIATIONS
The following abbreviations may be used in this Illustrated Parts Breakdown:
A/R................. As required
Cm ................. Centimeters
Ext. ................ External
Fwd................ Forward
Ga.................. Gauge
Grd, Gr........... Grade – when hardware lists a grade rating, it is imperative to maintain that rating when replacing parts.
HS ................. Hardened Steel
Hex ............... Hexagonal
Id, ID .............. Inner diameter
IPB................. Illustrated Parts Breakdown
JIC ................. Joint Industry Conference – an industry standard used to describe a fitting.
Lh, LH ............ Left Hand
MM................. Millimeters
Mtg ................ Mounting
n/s ................. Not Shown – parts that are not shown but are serviceable.
No .................. Number
NPT .............. National Pipe thread
NPTF ............. National Pipe Thread, Fine
OD ................ Outer diameter
p/n ................. Part number
Ref ................. Reference
Rev ................ Reverse Rh
RH ................ Right hand
Str .................. Straight – usually to describe a hydraulic or pneumatic fitting (vs. elbow)
