Table 4-1 describes the default functions of buttons, knobs, and controls. Some can be
programmed for different functions; see Section 6.4 for more information.
Table 4-1: Radio Controls, Indicators, and Connectors
CONTROL/INDICATOR
FUNCTION
Power On/Off
Volume Control
Turn knob clockwise to power on the radio and increase volume.
Turn counter-clockwise to decrease volume and put the radio into standby.
Minimum volume levels can be programmed into the radio to prevent missed calls
due to a low volume setting.
Group/Channel
Selection
Menu Selection
• Rotate to select the available groups or channels.
• While on the main display, press this knob to show the programmable button
function labels. Press again to hide labels.
• Within a menu, rotate to scroll up or down through available menu selections.
• Within a menu, press this knob to select the currently highlighted menu item,
similar to an Enter button.
Microphone
Connector
Connection for hand-held microphones.
Emergency Button
Press to declare an emergency. An Emergency Key Delay can be programmed
in the radio. This delay defines the length of time the emergency button must be
held before an emergency transmission is sent.
Navigation Pad
[Left, Right, Up, Down,
and Select (KMM)]
Navigates menu items.
In addition:
• Press the left navigation button while on the main display to access Channel
Information.
• Press the down navigation button while on the main display to display the
functions assigned to programmable buttons and to Ext I/O In.
• Press the up navigation button to display Missed Call info.
• Press the right navigation button to end or reject an I-Call.
• The Select button on the KMM selects the currently highlighted menu item,
similar to an Enter button.
12-Button Alpha-
Numeric Keypad (KMM)
By default, used to enter text or numbers. Can be programmed for various functions
(see Section 6.4).
Menu Button
From the Main Display, press this button to access the menu. Depending on
radio programming, pressing this button accesses the top-level list of menus or
accesses the Call Menu directly. While in a menu, press this button to return to
the main display.
USB Connector
Connection for USB accessory (e.g., Programming Cable).
Programmable Buttons
Programmable dynamic keys. See Section 6.4 for the functions that can be
programmed. Press the Group/Channel Selection Knob to display the function
labels for each button.
NOTE

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
