Table 4-5: Menu Navigation
MENUS
DESCRIPTION
CALL MENU:
EXIT EMERGENCY MODE
Exits emergency. See Section 4.27 for more information.
TALKAROUND MODE
Enable/disable talkaround. See Section 4.18 for more information.
TONE ENCODE
Analog conventional only - Transmits a programmed tone sequence on the current
radio system and channel. See Section 5.18 for more information.
INDIVIDUAL CALL
Allows you to select an individual for an individual call. See Section 4.13 for more
information.
PHONE CALL
Allows the user to initiate a telephone interconnect call. See Section 4.20 for more
information.
CHANGE TLKGRP
Change the selected talkgroup. See Section 4.12.
CALL ALERT
Select a group for Call Alert transmission. See Section 4.19.
CHANNEL GUARD
Select the Transmit and/or Receive Channel Guard tone. See Section 4.17.
SCAN MENU:
START SCAN/STOP SCAN
Start or stop scan operation. See Sections 4.22 and 4.23.
SCAN LISTS
View/Edit available scan lists. See Section 5.13.
ASSIGNED CUSTOM LIST
Create, View, and Edit Custom Scan Lists. See Section 5.13.6.
SITE ROAMING
Enable/Disable Wide Area System Scan. See Section 5.13.7.
SITE ALIAS
Select an available site from this list to lock the radio to; i.e., prevent the radio from
roaming. This is also known as Site Lock. See Section 5.13.8 for more
information.
SECURITY MENU:
ZEROIZE KEYS
Removes all encryption keys from the radio. See Section 5.19.2.
ENCRYPTION
Enable/Disable encryption. See Section 4.16.
GLOBAL ENCRYPTION
Enable/Disable Global Encryption. See Section 5.19.4.
GLOBAL KEY
Select the Global Key. Only available if Global Encryption is Enabled. See Section
5.19.4.
ACTIVE KEYSET
Select the Active Keyset. See Section 5.19.5.
KEY LIST
View available key lists. See Section 5.19.6.
OTAR
Enable/disable Over-the-Air Rekeying (OTAR). See Section 5.19.8.
OTAR REKEY
Request that the KMF updates the keys in the radio. See Section 5.19.8.
MESSAGES MENU:
RADIO STATUS
Used to send a status condition to the site without making a voice call. See
Section 5.14.
RADIO MESSAGE
Used to send a message to the site without making a voice call. See Section 5.15.
TEXTLINK MESSAGES
Allows the user to send a Radio TextLink message. See Section 5.16.1.
TEXTLINK FORMS
Allows the user to send a Radio TextLink form. See Section 5.16.2.
TEXTLINK MAILBOX
Contains received Radio TextLink messages. See Section 5.16.3.
FAULTS/ALERTS
Displays radio faults and alerts. See Section 5.17.
UTILITY MENU:
AUDIO SETTINGS:
• MASTER
Allows the user to enable or disable the master volume control. When enabled, it
allows remote control heads to control the volume of the speaker attached to the
back of the radio. When disabled, the volume knob on a remote-mount control
head only controls the volume of the speaker attached to the control head.
•
SPEAKER
Mute or unmute the speaker audio.
•
NOISE CANCELLATION
Enable or disable Noise Cancellation. See Section 4.15.
•
TONES
Enable or disable radio side tones.
•
KEYPAD TONES
Enable or disable tones that sound when the radio’s keypad buttons are pressed.

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
