Harris XL Series User Manual

14221-1850-2000, Rev. A
35
MENUS
DESCRIPTION
DISPLAY SETTINGS:
• COLOR SCHEME
Press the Group/Channel Select Knob to toggle the front and top display’s COLOR
SCHEME for optimum visibility in day or night conditions (NORMAL or
INVERTED).
• FRONT BACKLIGHT
Press the Group/Channel Select Knob to toggle the front display backlighting
between ON/OFF/MOMENTARY/MOMENTARY (OFF).
•
FRONT BRIGHTNESS
Press the left or right navigation buttons to dim or brighten the display.
• FRONT TIMEOUT
When the FRONT BACKLIGHT setting is MOMENTARY, this value specifies how
long the radio needs to be inactive before the front display’s backlight turns off.
Press the left or right navigation buttons to change the time in 0.5 second
increments.
• FRONT DISPLAY OFF
Turns the front display off completely. Press the Group/Channel Select Knob to
turn the front display back on.
• ACCENT BACKLIGHT
Allows the radio user to change the backlight for the buttons on the XL mobile
control head or KMM.
• ON - Backlight always on
• OFF - Backlight always off
• MOMENTARY - Backlight will come on at the beginning of the user interaction
and stay on, for the number of seconds determined by the Top/Accent
Backlight Timeout control, after the last user interaction.
• ACCENT BRIGHTNESS
Allows the user to change the level of brightness of the buttons on the control
head or KMM. Using the arrows, set the brightness level from 0 to 10.
• ACCENT TIMEOUT
This control allows the user to determine how long the Accent Backlight will stay lit
after the last user interaction. Enter a number from .5 to 30 in seconds.
•
DAY/NIGHT
Toggles between the Day and Night display modes.
• Day - When this option is selected, LCD, LED, and keypad backlight
brightness is set for Day mode.
• Night - When this option is selected, LCD, LED, and keypad backlight
brightness is set for Night mode.
• Auto - If this option is selected, the LCD, LED, and keypad backlight
brightness varies dynamically based on input at the light sensor on the control
head.
•
LEDs
Toggle indicator LEDs ON or OFF.
BLUETOOTH:
•
ENABLED (YES/NO)
Enable/disable Bluetooth. See Section 5.10 for more information.
• DISCOVERABLE (YES/NO)
Put the radio into discoverable mode. When the user sets discoverable to Yes,
the radio becomes visible to Bluetooth-enabled devices, and allows the user to
initiate Pairing.
• VOLUME CONTROL (YES/NO)
Select whether the radio volume control adjusts the output volume of the Bluetooth
speaker.
•
BLUETOOTH SPEAKER
Mute the Bluetooth speaker. If the external speaker is present but muted and
mute is selected for the Bluetooth speaker, the external speaker will be unmuted.
• EXTERNAL SPEAKER
Mute the external speaker. If the Bluetooth speaker is paired, connected, but
muted and the external speaker is muted, the Bluetooth speaker will be unmuted.
• PAIRING MGMT
Access pairing management menu to view, add, or delete Bluetooth devices. See
Section 5.10 for more information.
CLOCK SETTINGS:
•
TIME FORMAT
Select 12 Hour, 24 Hour, 12 Hour w/ Date Toggle, or 24 Hour w/Date Toggle
display format.
•
TIME ZONE
Set time zone relative to Universal Time Coordinated (UTC).

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
