Harris XL Series User Manual

14221-1850-2000, Rev. A
36
MENUS
DESCRIPTION
GPS SETTINGS:
•
GPS (ENABLED/DISABLED)
Enable/disable GPS.
• POSITION INFO
Displays GPS, Latitude, Longitude, and Altitude information. From this menu, click
NEXT to access SA INFO (see Section 5.2).
• ANGULAR UNITS
Set unit of measurement of displayed angular units: CARDINAL, DEGREES, or
MILS.
•
LINEAR UNITS
Set unit of measurement of displayed linear units: STATUTE, METRIC, or
NAUTICAL.
• POSITION FORMAT
Set format of displayed position information: Latitude/Longitude Decimal Degrees
(LAT LONG DD), Latitude/Longitude Degrees Minutes Seconds (LAT/LONG
DMS), LAT/LONG DM, Military Grid Reference System (MGRS), or Universal
Transverse Mercator (UTM).
•
SITUATION AWARENESS
NETWORKING
When Enabled, the radio sends GPS data to a Harris-supplied PC client using
Remote Network Driver Interface Specification (RNDIS) networking.
PROGRAM:
•
ACTIVATE PLAN
View/Activate a personality. See Section 5.1.
•
PROFILES
Change current profile. See Section 4.14.
MAINTENANCE:
•
RADIO INFO
Displays radio information, i.e., ESN, software revisions, and firmware revisions.
•
TESTS
Allows service personnel to run radio tests.
•
PH2 LC DISPLAY
For field service use only.
•
DISPLAY RSSI
When enabled, RSSI is displayed on the RSSI screen and in the bottom of the
main display. -130 dBm is displayed when there is no received signal.
• TCXO TUNING
For field service personnel only. Improper adjustment will result in loss of
communications.
•
FEATURE INFO
Displays what features are enabled on your radio.
WIFI CLIENT:
Displays the list of available Wi-Fi clients and the status of Wi-Fi Connection (a
question mark indicates the Wi-Fi network is in the process of connecting; a check
mark indicates the Wi-Fi Network is connected).
• POWER ON
Turn Wi-Fi on/off.
• ADD NEW
Displays the list of Trusted Wi-Fi Networks and is populated when Wi-Fi is
powered on. You can view, add, modify, and remove a Wi-Fi Network.
ICON GLOSSARY
Defines icons displayed by the radio.
USER LOGIN
Allows the user to enter a User ID and or Password to log into the P25 system
(see Section 4.4.1).
INSTALL GPP SOFTWARE:
Select a GPP package to install.
CHANGE LANGUAGE
Scroll up or down until the desired language is highlighted and then press
Group/Channel Select Knob.
CHANGE PIN
Allows you to change your PIN.
ZONE MENU:
View or change zones/systems (see Sections 4.10 and 5.3).

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
