HBK FUSION - (Optional) Import Channel Setup to HBK ADVANTAGE

(Optional) Import channel setup to HBK ADVANTAGE
NOTE
l
Only one user can use a device at a time.
l
Use the Filter Devices field to locate the relevant device or devices for your project.
(Optional) Import channel setup to HBK ADVANTAGE
It is possible to set up and modify channel properties directly in HBK ADVANTAGE, but an easier method is
to import the configuration from the HBK COMPANION mobile app (requires the app is downloaded on an
Android™ mobile device).
1. Open the mobile app.
2. Click Export project.
3. From the list of projects, select the one you have created for this test setup.
4. Click Export from the context menu.
5. You can then select to export to any suitable service such as your default email app, Google Drive™,
Microsoft
®
OneDrive
®
or to the device (for transfer to the PC).
6. Export the project file (as *.csv) with a unique name.
7. In HBK ADVANTAGE PC application, click Import in the toolbar.
8. Select the .csv file you exported from the mobile app and click Open.
The software will automatically recognize the relevant channel(s) from the HBK COMPANION app, and
configure channel properties accordingly, including:
l
Channel name
l
Sensor type
l
Bridge factor
l
Bridge excitation
l
Wiring
l
Scaling type
l
Gain
l
Gauge factor
