Correct positioning during operation
Correct positioning during operation
Frames in a rack
Rack mounting requires a 19-inch, 4U rack, with at least 1U between racks for proper air circulation. It is
recommended to use a rack that is open in the front and back, to easily see the status LEDs, to
connect/disconnect sensor cables and to access the power and LAN cables.
There should be enough space below and behind the mounted frame to allow free airflow for optimal
cooling of the hardware.
Frames on a tabletop
For optimal cooling of the hardware, the feet must always be extended during operation.
There should also be enough space behind the frame to allow free airflow.
Boards in the frame
Boards are not stand-alone devices and must be mounted in a frame to function. Lock the board into
position before operation.
