Connect the sensor cable to an input board
l
Pin 6: Not connected
l
Pin 7: Sense –
l
Pin 8: Not connected
Connecting the TEDS chip:
In addition, there are two ways to connect the TEDS chip:
l
0-wire: TEDS chip is inserted between pins 2 and 7
l
1-wire: TEDS chip is inserted between pins 4 and 5
EMC-immune cabling
To have an EMC-immune cabling, a special wire assignment is used. See "Testing with high EMC immunity"
on page16 for more information.
Resistance thermometers
Board type: B201-10
Connector type: 10×RJ45 (each with 8 pins)
Resistance thermometers Pt100/500/1000 are connected the same as the quarter bridge in a 4-wire
configuration.
Connect the sensor cable to an input board
NOTE
l
Connect the frame to a PC with HBK ADVANTAGE installed or to the corporate LAN via a
network switch before connecting the sensors.
l
Input boards must be in the frame during connection.
1. Connect each cable connected to a sensor to the appropriate connector on an input board in the
frame.
2. Open HBK ADVANTAGE software.
3. Go to Project > Channels in the software to check that your HBK FUSION device is detected and that
the sensors have been connected correctly.
All frames that are connected to the PC or LAN and each input board within that frame will show up as an
available device in HBK ADVANTAGE. Every device's name, IP address, serial number, location and firmware
version are read by the software. To change the name and location of the device, go to Home > Devices,
select the relevant cell in the Devices table and enter a new value.
- 30 -
