When the sensor is a potentiometer
Characteristics
For each channel, individual sensor scaling can be defined and applied. The scaling type will determine what
other parameters need to be defined.
Go to "Sensor characteristics" on the facing page for information on these parameters.
When the sensor is a potentiometer
Wiring: The connector wiring for the selected sensor. Only 5-wire is supported.
Connector pinning
Use the diagram to confirm that the sensor pinning matches the wiring of the sensor type.
Figure 3-4 Example of a 5-wire potentiometer as shown in HBK ADVANTAGE
Characteristics
For each channel, individual sensor scaling can be defined and applied. The scaling type will determine what
other parameters need to be defined.
Go to "Sensor characteristics" on the facing page for information on these parameters.
When the sensor is a CCLD transducer
This includes IEPE/CCLD accelerometers and microphones.
CCLD
Floating: Select to apply floating channel configuration (Yes) or to use the default ground referenced channel
configuration (No).
Connector pinning
Transducers are connected via a cable directly into the channel connector. The diagram reflects that simple
connection.
