Power
Power
The frame should be positioned to allow easy access to the AC connector. When the frame is connected to
mains power and the rear switch is in the ON position, power will be consumed.
See the Frame specifications for all power specifications.
NOTE
l
Boards are not stand-alone devices and must be mounted in a frame to function.
l
After an unexpected power loss, the hardware will automatically return to the last power state
when power is restored.
Connecting power
The power inlet and the protective ground connection are located at the rear of the frame. A mains power
cable, which is in accordance with the destination country's standards, is shipped with HBK FUSION.
The power switch is also located at the rear of the frame. Ensure the power switch is ON.
Disconnecting
To switch off the hardware, the power switch must be in the OFF position.
To disconnect the hardware and its power supply from the AC supply completely, unplug the power cable.
Network setup
The supplied LAN cable is a CAT5e Ethernet cable.
See the Frame specifications for all network specifications.
NOTE
l
Boards are not stand-alone devices and must be mounted in a frame to function.
l
It is recommended to connect the frame to Ethernet switch (at least 1Gbit). A switch allows a PC
to communicate locally with HBK FUSION using a dedicated high-speed connection without
burdening the company network with potentially high data rates. It simply plugs in and requires
no network configuration.
