Edit network settings
You can update the firmware for both frames and boards:
l
Directly in HBK ADVANTAGE: Go to Home > Devices and click Maintenance for the relevant device.
l
Via the device web page: In a web browser, enter the device's IP address in the address bar.
In both cases, you will access the device's web page. To run the update:
1. Go to the Firmware tab.
2. Click Select Firmware File.
3. Locate the saved firmware file (*.fw) on your PC or network drive.
If you are viewing the web page from the PC withHBK ADVANTAGE installed, the firmware installed
with the software can be found at C:\Program Files\HBK\ADVANTAGE\Measurement\Firmware.
4. Click Start Update to install. A status bar will advise you on update status.
Edit network settings
WARNING
Changing the device's network settings may break the connection with your web browser and
device web page.
Each device must have a unique IP address on the LAN. The IP address can be obtained in different ways:
l
Using DHCP: (default) A Dynamic Host Configuration Protocol (DHCP) server on the network
automatically assigns an IP address to the device when it connects to the network.
l
Manually: You set up a static IP address that does not automatically change.
On the device web page, you can change the default setting from DHCP and enter static IP address
information.
For both frames and boards:
1. In a web browser, enter the device's IP address in the address bar.
2. Go to the Settings tab.
3. Under Network Settings, remove the check mark from Automatically configure network (DHCP).
4. Enter an IP address, for example 172.17.123.234.
5. Enter the Netmask (subnet mask), for example 255.255.0.0.
- 64 -
