Release Info
Release Info
Version:
Version 2022.0
Release date:
November 2022
Manufacturer:
Hottinger Bruel & Kjaer A/S
Teknikerbyen 28
DK-2830 Virum
Denmark
Phone: +45 77412000
Fax: +45 77412100
Email: info@hbkworld.com
About the system
The HBK FUSION modular system allows the test equipment to easily grow with your testing needs. Start
with a single board in a frame, then add up to 15 more boards to expand your channel count. Add more
frames and boards as needed.
The frame
Each HF-16 frame houses up to 16 boards in a robust casing for industrial and rigourous everyday use.
Frames (with one or more boards) can be used for single front-end systems, or as part of a distributed
system.
Sample synchronisation, using precision time protocol (PTP), enables communication between the boards in
the frame and between frames on a system level.
Boards lock into place within the frame and can be easily swapped or removed without the use of any tools,
allowing you to configure and reconfigure your front end, or send a board for calibration.
See the HBK FUSION datasheet for specifications.
The boards
Bridge board
Bridge Board B201-10 is a 10-channel input board with a signal bandwidth up to 2kHz.
RJ45 channel connectors allow for quick and easy connection of sensors without soldering, and a patented
wiring configuration compensates for wire resistance, eliminating the need for shunting.
- 8 -
