Bridge board sample rate/filter combinations
50 20000 500
100 20000 1000
200 20000 2000
500 20000 50000
1000 20000 10000
2000 20000 20000
5000 20000 20000
2
Butterwoth IIR filter low-pass
Cut-off
(Hz)
Max. Sampling Rate
(S/s)
Min. Sampling Rate
1
(S/s)
0.01 10 1
0.02 50 1
0.05 100 1
0.1 100 1
0.2 500 2
0.5 1000 5
1 2000 10
2 2000 20
5 10000 50
10 20000 100
20 20000 200
50 20000 500
100 20000 1000
200 20000 2000
500 20000 5000
1000 20000 10000
2000 20000 20000
5000 20000 20000
2
1
Minimum sampling rate to avoid aliasing. Aliasing is allowed.
2
After this change, the signal may have aliasing problems.
