11
MP60, MP60DP
INTRODUCTION
Keyboard and
display
Galvanically isolated
power supply
24 V
mP
D
A
Counter
Intelligent signal
conditioning,
e.g. limit switches
MP60 / MP60DP
Scalable
analog output
Control inputs
Control outputs
Frequency outputs
CANopen interface
PROFIBUS‐DP inter
face (for MP60DP)
F1
F2
Reference zero
Error
Fig. 3.1 Block diagram of the MP60 module
Information
The amplifier type MP60 must be set on the DIP switch S12 (MP60) (see also page 13).
12 34
56
S12
ON
The switch positions must
not be changed!
