HBK MP60 - 9.6 Object dictionary: Manufacturer-specific objects

MP60, MP60DP
CAN INTERFACE DESCRIPTION
54
Error code Meaning
0 No error
1000 Fatal error (initial calibrator error)
5030 Transducer error
6311 Scaling error
6312 Analog output scaling error
F001 Measuring range overflow
F002 Analog output overflow
F020 Net overflow
FF03 Gross overflow
FF06 Peak value min.
FF07 Peak value max.
9.6 Object dictionary: Manufacturer-specific objects
Parameters that reference measured values are scaled true to number, and coded as
Long (32-bit integer). The position of the decimal point is defined in object 2120 Hex.
Alternatively, these quantities are also available as Float values (IEEE754‐19851985
32-bit format) – see page 65.
Notice: rop, rwp: PDO mappable
Index
(hex)
Sub
index
Name Format Attr. Values
Measured values
2000 1 Gross measured
value
integer32 rop
2001 1 Net measured value integer32 rop
2002 1 Maximum integer32 rop
2003 1 Minimum integer32 rop
2004 1 Peaktopeak integer32 rop
