55
MP60, MP60DP
CAN INTERFACE DESCRIPTION
ValuesAttr.FormatNameSub
index
Index
(hex)
2005 1 Measured value in
input quantity
integer32 ro Input range:
1MHz: 2 decimal places
100kHz: 3 decimal
places
10kHz: 4 decimal
places
1kHz: 5 decimal places
Pulse: 0 decimal places
2006 1 Analog output
value V
integer32 ro 3 decimal places
2010 1 Measured value
status
unsigned8 rop Bit 0: MV Overflow
Bit 1: Analog out Overfl.
Bit 2: Incorrect scaling
Bit 3: EEPROM error
Bits 4-7: Limit values
1-4
2011 1 MVstatus_2 unsigned32 rop Bit 0: Counter OVFL.
Bit 1: Input OVFL.
Bit 2: Overl. Gross
Bit 3: Overl. Net
Bit 4: Overl. Analog out
Bit 5: Overl. Maximum
Bit 6: Overl. Minimum
Bit 7: Negative overfl.
Bit 8: Limit value1
Bit 9: Limit value2
Bit 10: Limit value3
Bit 11: Limit value4
Bit 12: Scaling input
Bit 13: Scaling output
Bit 15: InCal.Err
Bit 16: Transducer error
Bit 17: CAN bus Off
Bit 18: CAN Tx error
