73
MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION
(MP60DP ONLY)
10.3 Configuration
The configuration defines which data content is exchanged during cyclic data
communication. The following data are available for selection:
Input values
Designation Meaning Length
Gross Gross measured value 1 or 2 words
Net Net measured value (gross minus tare value) 1 or 2 words
Max Content of Maximum memory 1 or 2 words
Min Content of Minimum memory 1 or 2 words
Pk-Pk Peak-to-peak, difference between Max and Min 1 or 2 words
Status1 Status word with state of the limit value switches
and general error bits
1 word
Status2 Status double word with differentiated error
identification
2 words
Output values
Designation Meaning Length
Control word Control word for triggering taring, zeroing, clearing
the peak value memory, parameter selection, etc.
1 word
LV1 Level at which limit switch 1 responds 1 or 2 words
LV2 Level at which limit switch 2 responds 1 or 2 words
LV3 Level at which limit switch 3 responds 1 or 2 words
LV4 Level at which limit switch 4 responds 1 or 2 words
The formats of the data content that is transmitted cyclically are specified in detail in
section 10.4. The measured values are optionally offered as 16-bit integer, 32-bit integer
or 32-bit float. The values are always scaled to physical quantity with selectable number
of decimal places. The indication whether the 16-bit or a 32-bit format is used, and the
number of decimal places, are defined in the parameterization telegram.
Typical combinations are predefined in the GSD file. If you need other combinations,
you can use the following specifications to extend the GSD file accordingly.
10.3.1 Defining custom configuration combinations
Only one configuration entry is available. The special identifier format must be used for it.
The manufacturer-specific data specifies the content, and so also the length, of the input
data, with a length of 2 bytes.
