77
MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION
(MP60DP ONLY)
MeaningNameBit
11 LV4 Status of limit switch 4
12 ScalInError Input scaling invalid
13 ScalOutError Output scaling invalid
14 GainError Nominal (rated) value exceeded
15 InCalError Defective working standard calibration
16 TransducerError Transducer error
17..31 res Reserved
Tab. 10.6 Status 2 content
10.4.2 Outputs (from the PLC to the MP60DP)
Limit values
Limit value levels are realized in the same format as measured values (16-bit integer,
32-bit integer or float format). The switching direction and hysteresis remain unchanged
and can be set via the control panel or the CAN bus.
Control word
Bit Name Meaning
0 ZERO 0-1 triggers automatic zeroing
1 TAR 0-1 triggers taring
2 SHUNT Shunt ON/OFF
3 res Reserved
4 CLRMAX 0-1 clears the MAX peak value memory
5 CLRMIN 0-1 clears the MIN peak value memory
6 HOLDMAX 1: Freeze MAX peak value memory
7 HOLDMIN 1: Freeze MIN peak value memory
8 PAR1 Parameter set selection bit 1
9 PAR2 Parameter set selection bit 2
10..15 res Reserved
Tab. 10.7 Control word content
