MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION
(MP60DP ONLY)
76
MeaningNameBit
6 LV3 Status of limit switch 3
7 LV4 Status of limit switch 4
8 PAR1 Active parameter set bit 1
9 PAR2 Active parameter set bit 2
10..14 res Reserved
15 MWiO Measured value OK
1)
(when bits 0,2,3=0)
1)
Significance of MWiO (measured value OK):
Negated OR combination of: MeasOvfl, ScalErr, EEPROMErr.
MeasOvfl is the OR combination of ADCOvfl, HardwOvfl, GrossOvfl, NetOvfl.
Tab. 10.5 Status 1 content
The parameter set number is binary-coded in 2 bits:
Bit 8 Bit 9 Parameter set no.
0 0 1
1 0 2
0 1 3
1 1 4
Status 2
The status double word 2 provides a more detailed error identification.
Bit Name Meaning
0 HardwOvfl Hardware overflow
1 ADCOvfl ADC overflow
2 GrossOvfl Gross signal overflow
3 NetOvfl Net signal overflow
4 AOutOvfl Analog output overflow
5 MaxOvfl Maximum overflow
6 MinOvfl Minimum overflow
7 NegOvfl Overflow in negative direction
8 LV1 Status of limit switch 1
9 LV2 Status of limit switch 2
10 LV3 Status of limit switch 3
