HBK MP60 - 10 PROFIBUS INTERFACE DESCRIPTION (MP60 DP ONLY); 10.1 Configuring and parameterizing

69
MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION (MP60DP ONLY)
10 PROFIBUS INTERFACE DESCRIPTION (MP60DP ONLY)
10.1 Configuring and parameterizing
u Start your configuration program (e.g. Step7); if you do not have a configuration
program, proceed as in section 10.3).
u Load the MP60DP GSD file (download from: https://www.hbm.com/de/2640/pme-die-
industrielle-messelektronik-mit-feldbusanbindung/?product_type_no=PME)
u Add an HBM device from the hardware catalog.
u From the hardware catalog, select the configuration you need on the Profibus.
Fig. 10.1 Hardware configuration
u Double-click the configured entries to open the properties window and select the
required parameters.
