MP60, MP60DP
INTRODUCTION
10
3 INTRODUCTION
3.1 Scope of supply and accessories
Scope of supply
S 1 MP60 module or 1MP60DP module
S 3 6-pin plug terminals, coded
Ordering no.: 3.3312-0427 (plug terminal 3);
3.3312-0428 (plug terminal 4); 3.3312-0426 (plug terminal 1)
S 1 10-pin ribbon cable female connector
S Additional spring for housing installation (included in pack)
S 1 MP60, MP60DP module operating manual
Accessories
S 15-pin Sub‐D connector for transducers Ordering no. 1-CON-P1024
S Setup toolkit (USB to CAN interface converter) Ordering no.: 1-PME-Setup-USB
3.2 General
MP60 module
The MP60 and MP60DP modules of the PME product line are frequency measurement
modules suitable for connecting incremental encoders, frequency encoders, and HBM
torque measurement flanges.
The modules are set up and parameterized via a keyboard and display, or by using the
PME Assistant. The PME Assistant provides a simple user interface under Windows for
parameterizing the modules (described in the "PME Assistant" online help).
