MP60, MP60DP
EXPLANATION OF THE MAIN PARAMETERS
8 EXPLANATION OF THE MAIN PARAMETERS
Group Parameter Meaning
DIALOG Password Set (change) password, 0000...9999
(factory-set default password: 0000)
PassStat Set password status:
active=password must be entered;
inactive=PME can be operated without entering password
I.ParaS to
I.AddFnc
Access to group via keyboard enabled or disabled.
PARAM.
SET
Load ? You can either load the factory setting, or one of the four
parameter sets that are saved.
Save? All the device settings can be saved power failsafe in four
parameter sets. Each time the mode of operation changes
from setting to measuring mode, you will be asked whether
or not the change is to be saved. The data is permanently
protected if you exit setting mode by confirming "Yes" to the
security prompt.
TRANS
DUCER
InpRang. 1 MHz, 100 kHz, 20 kHz, 10 kHz, 1 kHz, 5 MImp, 1 GImp
F2
2)
Frequency signal F2 is activated (if rotational speed and
direction of rotation are to be measured, F2 must be
activated). Signal F2 is phase-shifted by 90
o
.
ZeroIndx Zero index: Evaluate the zero signal
Frq x 4 Frequency quadrupled when F2 is active
(F2 inactive: frequency doubled). If frequency quadrupling
is activated, the input characteristic must be adjusted, as
double the number of pulses are evaluated.
RotDir The direction of rotation information is evaluated when F2 is
active
2)
. According to HBM definition, a negative direction
of rotation is indicated by a (-).
SwitThr Switching threshold as from which the input signal is
detected
GltchFlt Suppresses interference pulses with a duration of t3.2 μs
Zero kHz
Set input characteristic via transducer parameters
Zero kNm
Nom kHz
Nom kNm
