Enter the rated output (sensitivity) values of the T10F:
Group: TRANSDUCER
Unit: rpm
Input range: 1 MHz
F2 ON
Zero index OFF
Frq x 4 ON
2)
Direction of rotation ON (only possible if F1 and F2 are active)
Switching threshold 2.5 V
Glitch filter ON
Zero kHz 0
Zero rpm 0
Nom kHz 144 kHz
Nom rpm 6000 rpm
Transd. Err OFF
Information
If the frequency is quadrupled, the input characteristic must be adjusted. A rotational
speed of 6000 rpm then corresponds to 144 kHz (instead of 72 kHz with F2 = OFF).
Switch: F2 OFF ON OFF ON
Switch: Frq x 4 OFF OFF ON ON
Frequency display 1x 1x 2x 4x
Direction detection no yes no yes
2). Each edge is counted, not only the pulses; this quadruples the resolution
