HBK MP60 - 11 ERROR MESSAGES AND LED STATUS; Display Error Messages

MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION
(MP60DP ONLY)
78
10.5 Diagnosis
The MP60DP module provides device diagnostics as an external diagnostic function
which can be enabled via the parameterization diagram.
External diagnosis is 4 bytes long. The first byte contains the identifier for the version
number. The second byte contains the identifier for device diagnostics. In the third and
fourth bytes one bit each is reserved for different error causes.
Octet Bit Value Meaning
0 0..7 c1 Version 1
1 0..7 4 The total length of device diagnosis is 4 bytes
2 0 0
1
Hardware overflow
2 1 ADC overflow
2 2 0
1
Gross overflow
2 3 0
1
Net overflow
2 4 0
1
Analog output overflow
2 5 0
1
Maximum overflow
2 6 0
1
Minimum overflow
2 7 Reserved
3 0..3 Reserved
3 4 0
1
Input characteristic scaling error
3 5 0
1
Output characteristic scaling error
3 6 0
1
Nominal (rated) value exceeded
3 7 0
1
Defective working standard calibration
