MP60, MP60DP
PROFIBUS INTERFACE DESCRIPTION
(MP60DP ONLY)
74
CFG entry no. Meaning Contents
0 Channel 1 Special format with input and output, 9 words
maximum output, 13 words maximum input,
2 bytes comment length (data)
The subsequent input and output data can be configured for cyclic data communication.
The choice of which data will actually be transmitted, is communicated via the
manufacturer-specific data of the special identification format.
Configuration
manufacturer-
specific Data
Length of cyclic
data inputs
Length of cyclic
data outputs
Cyclic data content
Byte no. Bit no. (words) (words)
Input values:
0 0 1(2) Gross
0 1 1(2) Net
0 2 1(2) Max
0 3 1(2) Min
0 4 1(2) Peaktopeak
0 5 1 Status1
0 6 2 Status2
Output values:
1 0 1 Control word
1 1 1(2) Limit value level 1
1 2 1(2) Limit value level 2
1 3 1(2) Limit value level 3
1 4 1(2) Limit value level 4
Tab. 10.3 Selecting data content via manufacturer-specific data
The length of the input data is the sum of all the data lengths selected for transmission in
words. If you select the 32-bit format and the float format for measured values, the length
values in brackets must be used.
So the configuration telegram format is:
