MP60, MP60DP
CAN INTERFACE DESCRIPTION
56
ValuesAttr.FormatNameSub
index
Index
(hex)
2020 1 Input/output state unsigned8 rop Bits 0-3: Inputs 1-4
Bits 4-7: Outputs 1-4
2080 0 Edit mode unsigned8 ro 1: Edit mode on
0: Edit mode off
2081 0 Restart executed unsigned8 rw 1: Restart executed
0: Write = Clear
2082 0 Serial number Vis.string ro 12 characters
2083 0 Edit mode exited unsigned8 wo Measurement display
with any value after
writing
Dialog
2101 0 Dialog language unsigned16 rw 1500 German
1501 English
2103 0 Password integer16 rw
2104 1 Enable keyboard and
menu
unsigned16 rw 0: Enable input
1: Input disabled
Bit 0: Password input
Bit 1: Dialog
Bit 2: Parameter set
Bit 3: Display
Bit 4: Transducer
Bit 5: Conditioning
Bit 6: Analog output
Bit 7: Limit values
Bit 8: Peak values
Bit 9: Inputs/outputs
Bit 10: CAN
Bit 11: Additional
functions
Bit 12: Calibration
Bit 13: DP
Bit 15: Lock keyboard
Parameter sets
