Operation via fieldbus
ClipX
a4643-1.0 HBM: public 93
3 121 4 UINT32 RO CRC of a param. set
0 in RAM cache
0x4272 1
3 122 4 UINT32 RO CRC of a param. set
1 in RAM cache
0x4272 2
3 123 4 UINT32 RO CRC of a param. set
2 in RAM cache
0x4272 3
3 124 4 UINT32 RO CRC of a param. set
3 in RAM cache
0x4272 4
3 125 4 UINT32 RO CRC of a param. set
4 in RAM cache
0x4272 5
3 126 4 UINT32 RO CRC of a param. set
5 in RAM cache
0x4272 6
3 127 4 UINT32 RO CRC of a param. set
6 in RAM cache
0x4272 7
3 128 4 UINT32 RO CRC of a param. set
7 in RAM cache
0x4272 8
3 129 4 UINT32 RO CRC of a param. set
8 in RAM cache
0x4272 9
3 130 4 UINT32 RO CRC of a param. set
9 in RAM cache
0x4272 10
4 1 1 UINT8 RO Device type count 0x1000 0
4 2 4 UINT32 RO Device type 0x1000 1
4 3 1 UINT8 RO Digital IN read count 0x6000 0
4 4 1 UINT8 RO Digital IN read all
lines
0x6000 1
4 10 1 UINT8 RO Field value count 0x6100 0
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
