HDG Compact 25 - Delivery System Versions

4 Planning and installation – Planning the heating system
41
DELIVERY SYSTEM VERSIONS
Delivery version 1 - Dosage directly to TBZ
1Dosage
2 Feeding system
Delivery version 2 - Dosage, conveyor auger to TBZ
1 Dosage system II (motor of delivery system runs along with do-
sage system)
2Dosage
3 Feeding system
Figure 4/2 - Delivery system version 1
1
2
Figure 4/3 - Delivery system version 2
1
3
2
