HDG Compact 25 - Information Level

6 Using the heating system – Structure of the menus
112
INFORMATION LEVEL
No. Display Description
i-01 Control
Combustion control
Boiler 80/75?
Return 60/60°C
• Operating status
Configured control type
Boiler temperature set/actual
Return temperature set/actual
i-02 Control
Chamb.temp
550/540?
O2 7.0/6.9%
Fuel 70/70%
• Operating status
Combustion chamber temp. set/actual
Residual oxygen set/actual
Fuel quantity set/actual
i-03 Control
Outside temp. 8/
8°C
Flue gas temp. 165°C
• Heating required according to:
Outside temperature mean/current
Current flue gas temperature
i-04 Times
Control
01:29:36
• Times
Currently running times of the operational states
i-05 Demand
External 0°C
Accumulator 80°C
• Required preset boiler temperature
via an external contact
via accumulator
i-06 Demand HC ctrl.
HC1: 33°C HC2: 45°C
HC3: 30°C HC4: 32°C
HC5: 45°C HC6: 31°C
• Demand on the respective heating circuits
i-07 Demand DHW
DHW1:60°C DHW2: 60°C
• Demand on the respective domestic hot water tanks
i-08 Boiler
Dosage 60%
Primary air 38%
Secondary air 52%
• Boiler settings
Fuel quantity
Primary air setting
Secondary air setting
i-09 Boiler
Combust. air fan 100%
Ign. attempts 3/0
Flue gas fan 0/ 0%
• Boiler settings
Combustion fan setting
Number of ignition attempts
Rpm flue gas fan
i-10 Mixer return
Mixer control
Return 60/60°C
Pump On
• Return temperature control
Mixer operating status
Return temperature set/actual
Pump status (on/off)
Table 6/2 - Information level
