HDG Compact 25 - Saving Operating Parameters

5 Commissioning the system – Procedure
97
SAVING OPERATING PARAMETERS
Once the heating system has been configured, i.e. all of the parame-
ters have been adjusted, the set of parameters must be saved.
1. Simultaneously press the Plus and Enter buttons.
✓ The display changes to the service level.
✓ The cursor is positioned on the parameter group 1-General.
2. Press the Enter button.
3. Using the Down button, scroll to the parameter group
General 1-06.
4. Press the Enter button.
✓ The cursor flashes on 0.
5. Increase the value to 1 with the Plus button.
6. Press the Enter button.
✓ The settings of the initial commissioning are saved and can be re-
loaded at any time if lost by calling up the parameter
General 1-07.
✓ The setting of the parameters is completed.
Enter
Enter
No. Display Description
1-06 General information
Operating parameters
save
(0) 0
• The set operating parameters can be saved.
Table 5/8 - Saving operating parameters
Enter
Enter
