71
17.Set the position indicator (1) for the pressure equalisation regu-
lator to approximately "half open".
✓ The pressure equalisation hose is connected.
C
ONNECTING THE FEEDING
SYSTEM
18.Insert the cable of the feeding system through the opening pro-
vided for it on the cladding.
19.Connect the plug of the feeding system to the circuit board.
✎ See the enclosed circuit diagram “HDG Compatronic”.
✓ The feeding system is connected.
Figure 4/40 - Attaching the pressure equalisation hose
