HDG Compact 25 - Page 90

5 Commissioning the system – Procedure
90
3. After selecting the respective actuator, press the Plus or Minus
button.
✓ The drives are controlled with the Plus or Minus buttons.
4. Check that the following actuators work properly:
No. Display Description
h-01 Feeding system
Current: 0.000 A
Off
Forward (+) Back (-)
Feeding system
Plus button: Feeding system runs in the direction of tur-
ning
Minus button: Feeding system runs opposite to the direc-
tion of turning
h-02 Dosage
Current: 0.000 A
Off
Forward (+) Back (-)
Dosage
Plus button: Dosage system runs in the direction of tur-
ning
Minus button: Dosage system runs opposite to the direc-
tion of turning
h-03 Delivery system
Current: 0.000 A
Off
Forward (+) Back (-)
Delivery system
Plus button: Delivery system runs in the direction of tur-
ning
Minus button: Delivery system runs opposite to the direc-
tion of turning
h-04 Fill system
Quantity 60%
Off
Start (+) Stop (-)
Fill system
Plus button: Feeding system runs in continuous operation
Minus button: Feeding system switches off
h-04 Delivery system
Suction
Start with + button
Suction system extraction
Plus button: Vacuum fan starts
h-05 De-ashing
Off
Start (+) Stop (-)
De-ashing
Plus button: Ash removal augers switch on
Minus button: Ash removal augers switch off
h-06 Tip grate
Tip up
Limit
switch 0
Start (+) Stop (-)
Tip grate
Plus button: Grate tips down
Minus button: Grate tips up
Table 5/6 - Actuators in manual operation
