Hisense AVWT-192FFFH User Manual

6
General Data
2. General Data
2.1 General Data
Capacity(RT) 6 8 10 12
Model
Outdoor Model AVWT-72FFFH AVWT-96FFFH AVWT-120FFFH AVWT-144FFFH
Conbination AVWT-72FFFH AVWT-96FFFH AVWT-120FFFH AVWT-144FFFH
Power Supply 208/230V 3PH 60Hz
Cooling
Operation*1*2
Nominal Cooling Capacity
Btu/h 69000 92000 114000 138000
kW 20.2 27.0 33.4 40.4
Power Consumption (Ducted/Non-ducted
)
kW 5.69/4.65 7.80/6.55 9.65/8.21 12.70/11.38
EER (Ducted/Non-ducted) (Btu/h)/W 12.15/14.80 11.80/14.05 11.80/13.90 10.85/12.10
Heating
Operation*1*2
Nominal Heating Capacity (47°F)
Btu/h 75000 100000 126000 150000
kW 22.0 29.3 36.9 44.0
Power Consumption (Ducted/Non-ducted
)
kW 6.27/5.30 7.96/7.15 10.45/8.58 13.46/12.19
COP 47°F(Ducted/Non-ducted) W/W 3.51/4.15 3.68/4.10 3.53/4.30 3.27/3.61
Low Temperature Heating
Capacity (17°F)
Btu/h 52500 70000 81000 105000
kW 15.4 20.5 23.7 30.8
Power Consumption (Ducted/Non-ducted
)
kW 6.64/5.72 8.58/7.74 9.92/8.43 13.11/12.42
COP 17°F(Ducted/Non-ducted) W/W 2.32/2.69 2.39/2.65 2.39/2.81 2.35/2.48
Electrical Parameter
MCA A 34.3 41.2 49.3 60.1
MOP A 45 50 60 80
Sound Pressure Level*3 Normal Mode dB(A) 59 60 62 62
Cabinet Color*4 — Ivory White
Outer
Dimensions
Height
in. 68-1/8 68-1/8 68-1/8 68-1/8
mm 1730 1730 1730 1730
Width
in. 37-13/32 37-13/32 47-5/8 53-5/32
mm 950 950 1210 1350
Depth
in. 29-17/32 29-17/32 29-17/32 29-17/32
mm 750 750 750 750
Packing Dimensions
Height
in. 76-3/4 76-3/4 76-3/4 76-3/4
mm 1950 1950 1950 1950
Width
in. 39-31/32 39-31/32 50-3/16 55-29/32
mm 1015 1015 1275 1420
Depth
in. 31-3/32 31-3/32 31-3/32 31-3/32
mm 790 790 790 790
Weight
Net Weight
lbs. 534 536 637 796
kg 242 243 289 361
Gross Weight
lbs. 595 597 705 864
kg 270 271 320 392
Refrigerating Installation
Compressor — Scroll Comp
Compressor Quantity — 1 1 1 2
Refrigeration
Oil
Type — FVC68D
Brand — Idemitsu Kosan
Charge(Total)
gal 1.5 1.5 2.0 2.3
L 6.0 6.0 7.0 8.4
Refrigerant Charge Before
Shipment
lbs. 13.2 13.2 19.4 21.6
kg 6.0 6.0 8.8 9.8
Refrigerant Flow Control — Micro-computer Control Expansion Valve
Heat Exchanger Type — Multi-Way Cross-Flow Finned Tube Type
Heat Recovery
Operation
System
Low Pressure Gas
Pipe
in. Φ3/4 Φ7/8 Φ1-1/8 Φ1-1/8
mm Φ19.05 Φ22.20 Φ28.60 Φ28.60
High/Low Pressure
Gas Pipe
in. Φ5/8 Φ3/4 Φ7/8 Φ7/8
mm Φ15.88 Φ19.05 Φ22.20 Φ22.20
Liquid Pipe
in. Φ3/8 Φ3/8 Φ1/2 Φ1/2
mm Φ9.53 Φ9.53 Φ12.70 Φ12.70
Heat Pump
Operation
System
High/Low Pressure
Gas Pipe
in. Φ3/4 Φ7/8 Φ1-1/8 Φ1-1/8
mm Φ19.05 Φ22.20 Φ28.60 Φ28.60
Liquid Pipe
in. Φ3/8 Φ3/8 Φ1/2 Φ1/2
mm Φ9.53 Φ9.53 Φ12.70 Φ12.70
Fan
Condenser Fan Quantity — 1 1 2 2
Air Flow Rate
CFM 6460 6460 7060 9430
m
3
/min 183 183 200 267
Hole for Power Supply Wiring
in. Φ1-23/32 Φ1-23/32 Φ1-23/32 Φ1-23/32
mm Φ43.70 Φ43.70 Φ43.70 Φ43.70
Hole for Control Line Wiring
in. Φ55/64 Φ55/64 Φ55/64 Φ55/64
mm Φ22.00 Φ22.00 Φ22.00 Φ22.00
Note:
*1.The above cooling and heating capacities show the capacities when the outdoor unit operating with the 100% rating of indoor units
.
Cooling Operation Conditions Heating Operation Conditions: Nominal Heating Condition Low Temp. Heating Condition
Indoor Air Inlet Temperature: 80°F DB (26.7°C DB) Indoor Air Inlet Temperature: 70°F DB (21.1°C DB) 70°F DB (21.1°C DB)
67°F WB (19.4°C WB)
Outdoor Air Inlet Temperature: 95°F DB (35°C DB) Outdoor Air Inlet Temperature: 47°F DB (8.3°C DB) 17°F DB (-8.3°C DB)
43°F WB (6.1°C WB) 15°F WB (-9.4°C WB)
Piping Length: 25ft. (7.6m), Piping Lift: 0ft. (0m)
*2.Rated capacity and e󰀩ciency are certied under AHRI Standard 1230. Ratings are subject to change without notice. Current certied ratings are
available at www.ahridirectory.org.
*
3.The above noise values are measured in the anechoic chamber without reected echo, therefore the impact of the reected echo must be included at the
scene.
Measurement point: 3.3ft. (1.0m) from the service cover surface and 4.9ft. (1.5m) from oor level.
*4.The nal appearance of outdoor units is subject to the actual products.
