Hisense AVWT-192FFFH User Manual

80
Outdoor Unit Installation
(5) When installing the outdoor unit, x the unit by anchor bolts (eld-supplied).
Position of Anchor Bolts
Secure the outdoor unit with the anchor bolts.
Model: 1
92
2-43/64
(68)
Model:
72~96
2-43/64
(68)
31-31/32
(812)
2-43/64
(68)
Model:
120
2-43/64
(68)
42-21/64
(1075)
43/64
(17)
43/64
(17)
28-17/64
(718)
43/64
(17)
43/64
(17)
28-17/64
(718)
4×25/32(20)×19/32( 15)
Hole of Anchor Bolt
4×25/32(20)×19/32(15)
Hole of Anchor Bolt
4×25/32(20)×19/32( 15)
Hole of Anchor Bolt
4×25/32(20)×19/32(15)
Hole of Anchor Bolt
43/64
(17)
43/64
(17)
28-17/64
(718)
57-41/64
(1464)
2-43/64
(68)
2-43/64
(68)
28-17/64
(718)
43/64
(17)
43/64
(17)
47-29/32
(1217)
Model: 1
44-168
2-43/64
(68)
2-43/64
(68)
Nut
Washer
Anchor Bolt
M12
Filled with Mortar
3-15/16(100)
Concrete
unit: in.(mm)
3.5 Drain Water Treatment
Drainage is discharged during heating and defrosting operation, and so is rain water.
Pay attention to the followings:
(1) Choose a place where well drainage is available, or provide a drain ditch.
