247
Servicing
TURN OFF all the power switches.
2.15 Removing Thermistor for Liquid Pipe
(1) Remove the front service cover according to the item 2.1 “Removing Front Service Cover”.
(2) Remove the electrical box cover according to the item 2.5 “Removing Electrical Box Cover”.
(3) Remove the rubber cement. Then,remove the thhermistor for the liquid pipe by pulling out the thermo clip from the pipe.
NOTE:
When removing the thermistor for the liquid pipe, take special care not to cause damage to your hands or the thermistor
with the valve stay xing the stop valve.
(4) Reassemble the thermistor for liquid pipe in the reverse procedure.
NOTE:
When reassembling the thermistor, x the thermistor with the vinyl pipe end downward to prevent water from entering the
pipe.
Tool
Wet Cloth, Burner, Pliers,
Phillips Screwdriver, Nippers
Seal Whole Circumference
with rubber cement
Pipe
Thermistor
Vinyl Tube
Thermo Clip
To Next Page
