General Data
■ Outdoor Unit
Model: AVWT-72*, AVWT-96*
Anchor bolt fixing hole
28-17/64(718
268
)
(Foundation bolt hole spacing)
Maintenance panel
Electrical box
Connection of refrigerant gas pipe
(low pressure) Connecti on by welding
2-43/64(68)
31-31/32(812)
2-43/64(68)
43/64(17)
43/64(17)
10-15/32(266)
2-1/64(51)
28-31/32(736)
2-23/64(60)
26-17/64(667)
1-17/32(39)
9-1/4(235)
8-21/32(220)
37-13/32(950)
9-1/4(235)
12-9/32(312)
9-19/64(236)
6-13/16(173)
(137)
25/32(20)
6-1/2
(165)
11-17/32(293)
Connection of refrigerant gas pipe
(high/low pressure) Connection by welding
Connection of refrigerant liquid pipe
Connection with flare opening
5-3/38
(129)
unit: in.(mm)
5-25/64
5-25/32
(147)
Φ
Φ
2.5 Dimensional Data
