240
Servicing
TURN OFF all the power switches.
2.12.4 Removing Reversing Valve Coil (RVR1, RVR2)
(1) Remove one (1) screw xing the reversing valve coil with a phillips screwdriver. If the screw is di󰀩cult to remove, use a
spanner or an adjustable wrench
(2) Remove the reversing valve coils.
Tool Phillips Screwdriver
Reversing Valve Coil
Screw
This is the unit front view.
