General Data
2.2 Component Data
Outdoor Heat Exchanger, Fan and Fan Motor
Model AVWT-72* AVWT-96* AVWT-120* AVWT-144*
Heat
Exchanger
Heat exchanger type - Multi-way cross-ow nned tube type
Tube
Material - Copper
Outside diameter in.(mm) 9/32 (7)
Rows - 3 3 3 3
Fin
Material - Aluminum
Pitch in.(mm) 1/16 (1.4) 1/16 (1.4) 1/16 (1.4) 1/16 (1.4)
Quantity - 1 1 2 2
Max. operating pressure psi(MPa) 601 (4.15)
Max. frontal area ft.²(m²) 26.15(2.43) 26.15(2.43) 35.15(3.26) 39.40(3.66)
Fan Part
Fan
Type - Axial-ow Fan
Quantity - 1 1 2 2
Outside diameter in.(mm) 25-23/64 (644) 25-23/64 (644) 21-27/64 (544) 25-23/64 (644)
Rotating speed rpm 840 870 1185+1185 960+960
Fan
motor
Type - Waterproof three-phase motor
Start-up mode - Soft driving
Nominal output power W 730 730 430+430 730+730
Quantity - 1 1 2 2
Insulation grade - E E E E
Model AVWT-168* AVWT-192*
Heat
Exchanger
Heat exchanger type - Multi-way cross-ow nned tube type
Tube
Material - Copper
Outside diameter in.(mm) 9/32 (7)
Rows - 3 3
Fin
Material - Aluminum
Pitch in.(mm) 1/16 (1.4) 1/16 (1.4)
Quantity - 2 2
Max. operating pressure psi(MPa) 601(4.15)
Max. frontal area in.²(m²) 39.40(3.66) 42.84(3.98)
Fan Part
Fan
Type - Axial-ow Fan
Quantity - 2 2
Outside diameter in.(mm) 25-23/64 (644) 25-23/64 (644)
Rotating speed rpm 960+960 1050+1050
Fan
motor
Type - Waterproof three-phase motor
Start-up mode - Soft driving
Nominal output power W 730+730 730+730
Quantity - 2 2
Insulation grade - E E
