General Data
Capacity(RT) 28 30 32
Model
Outdoor Model AVWT-336FFFH AVWT-360FFFH AVWT-384FFFH
Combination
AVWT-168FFFH AVWT-168FFFH AVWT-192FFFH
AVWT-168FFFH AVWT-192FFFH AVWT-192FFFH
/ /
Power Supply 208/230V 3PH 60Hz
Cooling Operation*1*2
Nominal Cooling Capacity
Btu/h 320000 344000 368000
kW 93.8 100.8 107.8
Power Consumption (Ducted/Non-ducted
）
kW 29.14/27.04 30.71/29.05 32.28/31.06
EER (Ducted/Non-ducted
）
(Btu/h)/W 10.99/11.84 11.19/11.84 11.40/11.84
Heating Operation*1*2
Nominal Heating Capacity (47
℉
)
Btu/h 340000 370000 400000
kW 99.6 108.4 117.2
Power Consumption (Ducted/Non-ducted
）
kW 31.02/28.54 33.38/30.97 35.74/33.40
COP 47
℉
(Ducted/Non-ducted
）
W/W 3.21/3.49 3.25/3.50 3.28/3.51
Low Temperature Heating Capacity (17
℉
)
Btu/h 230000 255000 280000
kW 67.4 74.7 82.0
Power Consumption (Ducted/Non-ducted
）
kW 32.10/28.68 33.65/30.67 35.20/32.66
COP 17
℉
(Ducted/Non-ducted
）
W/W 2.10/2.35 2.22/2.44 2.33/2.51
Electrical
Parameter
MCA A 62.3+62.3 62.3+78.1 78.1+78.1
MOP A 80+80 80+100 100+100
Sound Pressure
Level*3
Normal Mode dB(A) 65 66 66
Cabinet Color*4 — Ivory White
Outer Dimensions
Height
in. 68-1/8 68-1/8 68-1/8
mm 1730 1730 1730
Width
in. 53-5/32+53-5/32 53-5/32+63 63+63
mm 1350+1350 1350+1600 1600+1600
Depth
in. 29-17/32 29-17/32 29-17/32
mm 750 750 750
Packing Dimensions
Height
in. 76-3/4 76-3/4 76-3/4
mm 1950 1950 1950
Width
in. 55-29/32+55-29/32 55-29/32+65-9/16 65-9/16+65-9/16
mm 1420+1420 1420+1665 1665+1665
Depth
in. 31-3/32 31-3/32 31-3/32
mm 790 790 790
Weight
Net Weight
lbs. 798+798 798+858 858+858
kg 362+362 362+389 389+389
Gross Weight
lbs. 866+866 866+930 930+930
kg 393+393 393+422 422+422
Refrigeration System
Installation
Compressor — Scroll Comp
Compressor Quantity — 2+2 2+2 2+2
Refrigeration Oil
Type — FVC68D
Brand — Idemitsu Kosan
Charge(Total)
gal 2.2+2.2 2.2+2.3 2.3+2.3
L 8.4+8.4 8.4+8.6 8.6+8.6
Refrigerant Charge
Before Shipment
lbs. 21.6+21.6 21.6+25.4 25.4+25.4
kg 9.8+9.8 9.8+11.5 11.5+11.5
Refrigerant Flow Control — Micro-computer Control Expansion Valve
Heat Exchanger Type — Multi-Way Cross-Flow Finned Tube Type
Heat Recovery
Operation
System
Low Pressure Gas Pipe
in. Φ1-1/2 Φ1-1/2 Φ1-1/2
mm Φ38.10 Φ38.10 Φ38.10
High/Low Pressure Gas
Pipe
in. Φ1-1/8 Φ1-1/4 Φ1-1/4
mm Φ28.60 Φ31.75 Φ31.75
Liquid Pipe
in. Φ3/4 Φ3/4 Φ3/4
mm Φ19.05 Φ19.05 Φ19.05
Heat Pump
Operation
System
High/Low Pressure Gas
Pipe
in. Φ1-1/2 Φ1-1/2 Φ1-1/2
mm Φ38.10 Φ38.10 Φ38.10
Liquid Pipe
in. Φ3/4 Φ3/4 Φ3/4
mm Φ19.05 Φ19.05 Φ19.05
Fan
Condenser Fan Quantity — 2+2 2+2 2+2
Air Flow Rate
CFM 9430+9430 9430+12360 12360+12360
m³/min 267+267 267+350 350+350
Hole for Power Supply Wiring
in. Φ1-23/32 Φ1-23/32 Φ1-23/32
mm Φ43.70 Φ43.70 Φ43.70
Hole for Control Line Wiring
in. Φ55/64 Φ55/64 Φ55/64
mm Φ22.00 Φ22.00 Φ22.00
Note:
*1.The above cooling and heating capacities show the capacities when the outdoor unit operating with the 100% rating of indoor units
.
Cooling Operation Conditions Heating Operation Conditions: Nominal Heating Condition Low Temp. Heating Condition
Indoor Air Inlet Temperature: 80°F DB (26.7°C DB) Indoor Air Inlet Temperature: 70°F DB (21.1°C DB) 70°F DB (21.1°C DB)
67°F WB (19.4°C WB)
Outdoor Air Inlet Temperature: 95°F DB (35°C DB) Outdoor Air Inlet Temperature: 47°F DB (8.3°C DB) 17°F DB (-8.3°C DB)
43°F WB (6.1°C WB) 15°F WB (-9.4°C WB)
Piping Length: 25ft. (7.6m), Piping Lift: 0ft. (0m)
*2.Rated capacity and e󰀩ciency are certied under AHRI Standard 1230. Ratings are subject to change without notice. Current certied ratings are
available at www.ahridirectory.org.
*3.The above noise values are measured in the anechoic chamber without reected echo, therefore the impact of the reected echo must be included at the
scene.
Measurement point: 3.3ft. (1.0m) from the service cover surface and 4.9ft. (1.5m) from oor level.
*4.The nal appearance of outdoor units is subject to the actual products.
