245
Servicing
● AVWT-144~192FFFH
● AVWT-120FFFH
Tg Thermistor
(Evaporation Gas Line)
Te2 Thermistor
(Evaporation Liquid Line)
Te1 Thermistor
(Evaporation Liquid Line)
High Pressure Sensor
Low Pressure Sensor
PSH2
(High Pressure Switch)
Tbg Thermistor
(Sub Cooling Bypass Line)
Td2 Thermistor (Compressor)
Tchg Thermistor
(Sub Cooling Main Line)
PSH1
(High Pressure Switch)
Td1 Thermistor
Tsc
(inlet pipe of the subcooler）
Tg Thermistor
(Evaporation Gas Line)
Te2 Thermistor
(Evaporation Liquid Line)
Te1 Thermistor
(Evaporation Liquid Line)
High Pressure Sensor
Low Pressure Sensor
Td1 Thermistor
(Compressor)
Tchg Thermistor
(Sub Cooling Main Line)
PSH1
(High Pressure Switch)
Tbg Thermistor
(Sub Cooling Bypass Line)
Tsc
(inlet pipe of the subcooler）
