Hisense AVWT-192FFFH User Manual

29
Piping System
Model (kBtu/h) 216 (18RT) 240 (20RT) 264(22RT) 288 (24RT) 312(26RT)
Combination
of Basic Unit
Outdoor Unit A 120 (10RT) 120 (10RT) 144 (12RT) 144 (12RT) 168 (14RT)
Outdoor Unit B 96 (8RT) 120 (10RT) 120 (10RT) 144 (12RT) 144 (12RT)
Manifold Pipe HFQ-M32F
Piping Size
Φ in.(mm)
a
High/Low
Pressure Gas
1-1/8(28.6) 1-1/4(31.75) 1-1/4(31.75) 1-1/4(31.75) 1-1/4(31.75)
Liquid 5/8(15.88) 3/4(19.05) 3/4(19.05) 3/4(19.05) 3/4(19.05)
b
High/Low
Pressure Gas
1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6)
Liquid 1/2(12.7) 1/2(12.7) 1/2(12.7) 1/2(12.7) 1/2(12.7)
c
High/Low
Pressure Gas
7/8(22.2) 1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6)
Liquid 3/8(9.53) 1/2(12.7) 1/2(12.7) 1/2(12.7) 1/2(12.7)
Model (kBtu/h) 336 (28RT) 360 (30RT) 384 (32RT)
Combination of
Basic Unit
Outdoor Unit A 168 (14RT) 192 (16RT) 192 (16RT)
Outdoor Unit B 168 (14RT) 168 (14RT) 192 (16RT)
Manifold Pipe HFQ-M32F
Piping Size
Φ in.(mm)
a
High/Low
Pressure Gas
1-1/2(38.1) 1-1/2(38.1) 1-1/2(38.1)
Liquid 3/4(19.05) 3/4(19.05) 3/4(19.05)
b
High/Low
Pressure Gas
1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6)
Liquid 1/2(12.7) 5/8(15.88) 5/8(15.88)
c
High/Low
Pressure Gas
1-1/8(28.6) 1-1/8(28.6) 1-1/8(28.6)
Liquid 1/2(12.7) 1/2(12.7) 5/8(15.88)
