Piping System
①②
Piping between outdoor unit Refer to section 3.2.
③
Main Pipe (Basic Unit or Manifold Pipe 1 to First Branch)
Outdoor Unit
capacity (kBtu/h)
Gas (Φin.(mm)) Liquid (Φin.(mm))
Branch
Pipe Model
72 3/4(19.05) 3/8(9.53)
HFQ-102F
96 7/8(22.2) 3/8(9.53)
120~140 1-1/8(28.6) 1/2(12.7)
HFQ-162F
168 1-1/8(28.6) 1/2(12.7)
192 1-1/8(28.6) 5/8(15.88)
HFQ-242F
216 1-1/8(28.6) 5/8(15.88)
240 1-1/4(31.75) 3/4(19.05)
HFQ-302F264~312 1-1/4(31.75) 3/4(19.05)
336 1-1/2(38.1) 3/4(19.05)
360~456 1-1/2(38.1) 3/4(19.05) HFQ-462F
NOTE:
When maximum length of the equivalent refrigerant pipe (L1) from the outdoor unit/manifold pipe1 to the indoor unit is over
328 ft. (100m), the pipe size of high/low pressure gas and liquid line from basic unit/manifold pipe1 to rst branch should be
increased one size with the reducer (eld-supplied).
④
Pipe after rst branch (2 pipes portion)
Total Indoor Unit
(kBtu/h)
Gas
(Φin.(mm))
Liquid
(Φin.(mm))
Branch
Pipe Model
Q < 54 5/8(15.88) 3/8(9.53)
HFQ-102F
54≤ Q < 86 3/4(19.05) 3/8(9.53)
86≤ Q < 114 7/8(22.2) 3/8(9.53)
114≤ Q < 154 1-1/8(28.6) 1/2(12.7)
HFQ-162F
154≤ Q < 170 1-1/8(28.6) 1/2(12.7)
170≤ Q < 250 1-1/8(28.6) 5/8(15.88) HFQ-242F
250≤ Q < 344 1-1/4(31.75) 3/4(19.05)
HFQ-302F
344≤ Q < 544 1-1/2(38.1) 3/4(19.05)
544≤ Q < 552 1-5/8(41.3) 7/8(22.2)
HFQ-462F
552≤ Q < 654 1-3/4(44.5) 7/8(22.2)
654≤ Q 2(50.8) 1-1/8(28.6) HFQ-682F
NOTE:
Even if the equivalent refrigerant piping length (L1) is more than 328 ft. (100m), no need to increase the pipe size after rst
branch. If the branch pipe size is larger than the rst branch, adjust the branch pipe size to the rst branch. In case that the
selected pipe size after the rst branch is larger than the pipe size before the rst branch, use the same pipe size as the one
before the branch.
⑤
Pipe between last branch and indoor unit
4-Way Cassette Type and Mini 4-Way Cassette Type
Indoor Unit
(kBtu/h)
Air pipe
(Φin.(mm))
Liquid pipe
(Φin.(mm))
05~19 1/2(12.7) 1/4 (6.35)
22~54 5/8(15.88) 3/8(9.53)
Others
Indoor Unit (kBtu/h)
Air pipe
(Φin.(mm))
Liquid pipe
(Φin.(mm))
05~17 1/2(12.7) 1/4 (6.35)
18 5/8(15.88) 3/8(9.53)
19 5/8(15.88) 1/4(6.35)
22~54 5/8(15.88) 3/8(9.53)
NOTE:
(1) When the liquid piping length is longer than 49.2ft.(15m), use Φ3/8(9.53) pipe and reducer (eld-supplied) instead of
Φ1/4 (6.35) pipe.
(2) The pipe diameter should be the same as the indoor unit piping connection size.
