51
Capacities and Selection Data
Results
:
Concept Room 1 Room 2 Room 3 Room 4 Room 5 Room 6 Room 7
Model selected AVD-19* AVD-24* AVD-24* AVD-27* AVD-38* AVD-48* AVD-48*
Actual cooling capacity (Btu/h) 14,745 18,683 18,683 21,153 29,336 37,056 37,056
Actual heating capacity (Btu/h) 14,172 17,977 17,997 20,208 27884 35,758 35,758
Estimated cooling load (Btu/h) 13,470 17,250 17,250 20,700 27,930 30,760 30,760
Estimated heating load (Btu/h) 14,590 18,620 18,620 22,410 29,440 32,050 32,050
Concept Room 1+2+3+4+5+6+7
Actual total cooling capacity (Btu/h) 176,713
Actual total heating capacity (Btu/h) 169,734
Estimated total cooling load (Btu/h) 158,120
Estimated total heating load (Btu/h) 167,780
As can be seen, the actual total cooling and heating capacity are higher than the estimated total cooling and heating load.
Therefore, it can be said that the AVWT-192FFFH unit meets the minimum cooling and heating requirements set for the
system.
NOTE
If the actual total cooling / heating capacity calculated is lower than the estimated total cooling / heating load, the calculation
must be done again with the unit immediately.
