fiber cable with the specifications shown in Figure 3-98. One or more cables of th
same type is recommended to be prepared for spare. Table 3-99 shows the router
optical interface specifications for OC-48c/STM-16 (POS) single-mode connection
Figure 3-98 Single-Mode Optical Fiber Cable Specifications for OC-48c/STM-16 (POS
Table 3-104 Optical Interface Specifications for OC-48c/STM-16 (POS) Single-Mode
Connections
pecifications
Recommended model name: Hitachi Optical Fiber Cable SM1005-2M-C2SC-[ ]M (cord length in brackets)
Boundary with network: router’s connector
2-core SC
connector
Graded index single-mode fiber of 9.5/125 µm
core/clad, 1300 nm wavelength, max.
attenuation 0.3 dB/km (max. 2 km or 40 km)
2-core SC
connector
