5. SPECIFICATION
5-12
(4) Details of the setup menu
The following tables show the details of the items you can set up in each menu.
(1/3)
Top
menu
Setting item Default value Note
Main System Date When you set the system up for the
first time, be sure to configure these
two items.
System Time
Drive1 Automatically
recognized
(*1)
Drive2 Automatically
recognized
Drive3 Automatically
recognized
Boot
Options
Beep on boot Disabled This setting only turns the beep sound
on and off at startup. The beep sound
for indicating failure is not affected by
this setting and is always on.
Reset button function Reset Configures the function of the reset
switch.
If you change the setting to NMI (Non-
Maskable Interrupt), you can change
the reset switch to an NMI switch. (*2)
Quick Boot Mode Disabled If you change the setting to Enabled,
you can skip the memory check and the
startup time will be shortened.
In normal operation, specify Disabled
for the setting.
Correctable ECC Error Pass Specifies whether to display a message
and pause the startup or to ignore the
error and proceed with the startup
when a Correctable ECC Error is
detected.
System Memory Automatically
recognized
-
(*1) The DRIVE1 through 3 is assigned as indicated in the table below.
Name recognized
by the BIOS
Drive1 Drive2 Drive3
Connected device Drive bay 1
Drive bay 2 DVD drive
(*2) A setting change to “NMI” gives you more chances of non-maskable interrupt, thereby increasing the possibility of
successful memory dump initiated by the reset button at an error occurrence during OS startup/shutdown.
For information about a memory dump, see “8.2 Collecting a Memory Dump”.
